AS5247U

AS5247U

14-bit on-axis magnetic rotary position sensor with up to 14-bit binary incremental pulse count
データシート

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

AS5247U
AS5247U
データシート

製品仕様情報

  • Accurancy
    0.4 °
  • ASIL qualified
    ASIL D
  • Die in package
    dual
  • Operating ambient temperature 範囲
    -40 °C～150 °C
  • Output interface
    PWM, ABI, UVW, SPI
  • Resolution
    14 bit
  • Rotation speed (最大)
    28000 rpm
  • 技術
    magnetic
  • 機能
    on-axis angle position sensing
  • 車載用認定品
    AEC-Q100
  • 電源電圧
    3.3 V, 5 V
OPN
製品ステータス
インフィニオン パッケージ
パッケージ名
梱包サイズ
梱包形態
MSL (湿度感受性レベル)
防湿梱包
鉛フリー
ハロゲンフリー
RoHS対応
Infineon stock last updated:
High‑performance redundant 14‑bit rotary position sensor enabling fast and accurate 360° angle measurement for advanced motor control. Combines SPI with CRC, PWM, ABI (up to 4096 pulses/rev) and UVW outputs for seamless BLDC motor integration. DAEC™ delivers near‑zero latency at high speeds, while DFS™ improves low‑speed angle noise quality. Integrated safety diagnostics support up to ASIL‑D. Provides excellent stray field immunity in TQFP‑32.

特長

  • DAEC™ angle error comp. DFS™ filter system
  • Magnetic stray field immunity
  • ISO26262, diagnostics, ASIL-D capable, SEooC
  • AEC-Q100 Grade 0 qualified
  • Output interfaces: SPI, ABI, UVW,PWM

利点

  • Easy to use – saving costs on DSP
  • Higher durability and lower system costs (no shield needed)
  • Enabler for safety critical applications
  • Suitable for automotive applications
  • Versatile choice of the interface
