Active and preferred
RoHS準拠

KIT_PSOC4-HVPA-144K_LITE

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

KIT_PSOC4-HVPA-144K_LITE
KIT_PSOC4-HVPA-144K_LITE

製品詳細

推奨
OPN
KITPSOC4-HVPA-144KLITE
製品ステータス active and preferred
インフィニオンパッケージ N/A
パッケージ名 N/A
包装サイズ 1
包装形態 CONTAINER
水分レベル NA
モイスチャーパッキン NON DRY
鉛フリー No
ハロゲンフリー No
RoHS準拠 Yes
Infineon stock last updated:

製品ステータス
Active
インフィニオンパッケージ N/A
パッケージ名 -
包装サイズ 1
包装形態 CONTAINER
水分レベル NA
モイスチャーパッキン NON DRY
鉛フリー
ハロゲンフリー
RoHS対応
The PSOC™TM HV PA 144k Lite kit is a compact development kit designed for the PSOC™TM high-voltage (HV) precision-analog (PA) microcontroller, a fully integrated programmable embedded system ideal for lead acid battery monitoring and management applications. At the heart of this system lies an Arm Cortex-M0+ processor, which features programmable and reconfigurable analog and digital blocks.

機能

  • Two high-resolution ΔΣ ADCs (16-20+ bits) with automatic gain current channel and HV input divider voltage channel, ensuring precise measurements.
  • A range of digital peripherals, such as PWMs, to facilitate efficient control and communication.
  • Serial communication interfaces, including a LIN interface with an integrated PHY, enabling seamless connectivity.
  • A high-voltage subsystem capable of operating directly off a 12-V car battery, eliminating the need for additional power management components.

利点

  • Comprehensive platform for developers to design and test innovative battery management systems.

用途

Bill of Material

ドキュメント

ドキュメント

デザイン リソース

パートナー ソリューション
