TLS203B0EJ V50

The TLS203B0EJ V50 is a micropower, low noise, low dropout voltage 5 V regulator.
データシート
パッケージ
EA.
在庫あり

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

TLS203B0EJ V50
TLS203B0EJ V50
EA.
データシート

Product details

  • Currently planned availability until at least
    2038
  • Watchdog
    no
  • Status Output
    no
  • Dropout Voltage
    270 mV
  • Power Good
    no
  • Family
    OPTIREG™ linear Post Regulator
  • Base Product
    TLS203B0xxVxx
  • Hold
    no
  • Reset
    no
  • Regulator Type
    Post Regulator
  • Budgetary Price €/1k
    0.62
  • Output Voltage Type
    5.0 V
  • Output Current max
    300 mA
  • Operating Temperature
    -40 °C to 125 °C
  • Operating Voltage
    2.3 V to 20 V
  • Early Warning
    no
  • Enable (=Inhibit)
    yes
  • Accuracy
    2.5 %
  • Qualification
    Automotive
  • Over Voltage Protection
    no
  • Power Fail
    no
  • Quiescent Current
    30 µA
推奨
OPN
TLS203B0EJV50XUMA1
製品ステータス active and preferred
インフィニオンパッケージ
PG-DSO-8
パッケージ名 N/A
包装サイズ 2500
包装形態 TAPE & REEL
水分レベル 3
モイスチャーパッキン DRY
鉛フリー Yes
ハロゲンフリー Yes
RoHS準拠 Yes
Infineon stock last updated:
 EA. 在庫あり

製品ステータス
Active
インフィニオンパッケージ
PG-DSO-8
パッケージ名 -
包装サイズ 2500
包装形態 TAPE & REEL
水分レベル 3
モイスチャーパッキン DRY
鉛フリー
ハロゲンフリー
RoHS対応
EA.
在庫あり
Designed for use in battery-powered systems, the low quiescent current of 30 μA makes it an ideal choice. One feature of the TLS203B0EJV50 is its low output noise. By adding an external 10 nF bypass capacitor output noise values down to 42 μVRMS over a 10 Hz to 100 kHz bandwidth can be reached. The TLS203B0EJV50 voltage regulator is stable with output capacitors as small as 3.3 μF. Small ceramic capacitors can be used without the series resistance required by many other linear voltage regulators. Internal protection circuitry includes reverse battery protection, current limiting and reverse current protection. The TLS203B0EJV50 is a 5.0 V fixed output voltage variant and is available in a PG-DSO8 exposed pad package.

機能

  • Wide Input Voltage Range: up to 20 V
  • 300 mA Current Capability
  • Low Quiescent Current: 30μA
  • Low Dropout Voltage: 290 mV
  • Low Noise typ.: 42µV RMS(BW = 10 Hz to 100 kHz)
  • Fixed Output Voltage: 5.0 V
  • Enable Feature
  • Internal circuitry working down to 2.3 V
  • Very low Shutdown Current: < 1μA
  • No Protection Diodes Needed
  • Stable with ≥ 3.3 μF Output Capacitor
  • Stable with Aluminium, Tantalum or Ceramic Output Capacitors
  • Reverse Polarity Protection
  • Overcurrent and Overtemperature Protected
  • PG-DSO8 exposed pad package
  • Suitable for Use in Automotive Electronics as Post Regulator
  • Green Product (RoHS compliant)
  • AEC Qualified

利点

  • Wide input voltage range
  • Output ceramic caps supported
  • Low noise
