SLC37PDZXXX

40nm SLC3x products enhance user experience for excellent performance and flexibility

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

SLC37PDZXXX
SLC37PDZXXX

Product details

  • CPU
    32-bit Arm® SecurCore® SC300
  • NVM / 凌捷掩膜
    400 kByte to 512 kByte
  • RAM
    14 kByte
  • Applications
    wearables payment , multiapplication
  • Interfaces
    optional NRG™ (ISO/IEC 14443-3 type A with CRYPTO1), ISO 7816, ISO 14443 A/B, ISO 18092 passive mode, optimized for small antenna sizes
  • Leading Technologies
    Coil on Module, SOLID FLASH™
  • Ambient Temperature
    -25 °C to 85 °C
  • Symmetric Cryptography
    DES, 3DES, AES up to 256-bit
  • Delivery Forms
    6/8 pin dual-interface modules and contactless modules, sawn wafer, Coil on Module
  • Product Description
    dual-interface security cryptocontroller for multiapplication and wearables payment use cases supporting multi-interface
  • Certifications
    CC EAL6+ high targeted, CUP (targeted), EMVCo (targeted)
  • Additional Information
    Please note that xxx stands for NVM size, z – different interfaces
  • Asymmetric Cryptography
    ECC up to 521-bit, RSA up to 4096-bit
OPN
製品ステータス
インフィニオンパッケージ
パッケージ名
包装サイズ
包装形態
水分レベル
モイスチャーパッキン
鉛フリー
ハロゲンフリー
RoHS準拠
Infineon stock last updated:
The 40nm SLC37PDx product series improves user experience with boost contactless and performance experience and offers excellent flexibility.

機能

  • High-performance 32-bit CPU based on Arm® SecurCore® SC300 enhanced  by  Infineon Technologies’ cache security concept
  • Up to 512 KB SOLID FLASH™ NVM with free partitioning code/data and up to 16 KB RAM
  • Supporting interfaces: ISO14443 Type A/B & ISO18092 (NFC) contactless, ISO7816 contact based
  • EMVco and CC EAL 6+ certified
  • Certified efficient SW libraries for asymmetric (RSA, ECC) and symmetric (AES, 3DES) cryptography
  • CIPURSE™ crypto library upon request
  • ISS: Instruction Stream Signature for execution integrity

利点

  • Optimize time-to-market: Customers can benefit from fastest design-in of the SLC36PDx 40nm product series, as it supports wide range of applications from the smallest to most powerful chip in the market. R&D resources can be optimized.
  • Excellence in converging markets: The state of the art Arm® SecurCore® SC300 chip architecture of the 40nm SLC36PDx product series enables a CL boost performance for high demanding payment and multi-application uses cases.
  • Best fit for all regional variances: The product offering is designed for global markets and support specific regional market requirements. The excellent Infineon customer support within the regional organization around the globe enables a very fast time to market.
  • Innovations platform: The 40nm platform and its enhanced feature enables innovations, including market trends such as biometric authentication. Innovative ready to use delivery forms such as the SPA modules enable very fast design of new form factors within a few weeks.
