CYPM1211-42FNXI

Dual Role Port USB-C PD with USB Full-Speed device, including moist detection
データシート
ボード

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CYPM1211-42FNXI
CYPM1211-42FNXI
データシート

Product details

  • GPIOs
    20
  • SRAM
    8 kByte
  • USB Standard
    USB-PD 3.2
  • VBUS Short Protection
    N
  • VCONN FET
    N
  • Applications
    Personal care solutions, Power tools, Home appliances, Smart speakers
  • Software Tools
    ModusToolbox™
  • Battery series
    1S to 5S
  • Package Type
    42-ball CSP
  • Peak Reflow Temp
    260 °C
  • Family
    EZ-PD™ PMG1-S2
  • Flash
    128 kByte
  • Processor Type
    ARM® Cortex®-M0/M0+
  • Operating Temperature
    -40 °C to 85 °C
  • Operating Voltage
    4 V to 21.5 V
  • Temperature grade
    Industrial
  • Product Description
    MCU with crypto engine
  • Product Category
    High Voltage MCUs
OPN
製品ステータス
インフィニオンパッケージ
パッケージ名
包装サイズ
包装形態
水分レベル
モイスチャーパッキン
鉛フリー
ハロゲンフリー
RoHS準拠
Infineon stock last updated:
EZ-PDTM PMG1-S2 CYPM1211-42NFXI is the tray packing type option of the PMG1-S2, it supports Dual Role Port (DRP) USB-C PD applications and integrates a USB full-speed device controller.

機能

  • USB-C support and USB PD support
  • Moisture detection
  • Programmable MCU
  • Integrated legacy charging block
  • Apple charge support
  • Integrated hardware crypto block for authentication
  • Integrated 8-bit ADC for voltage monitoring
  • Integrated current sense block
  • Integrated digital blocks configurable
  • USB full-speed device controller
  • NFET gate drivers
  • System-level fault protection
