AS8579

AS8579

Accurate capacitive presence sensing
データシート

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

AS8579
AS8579
データシート

製品仕様情報

  • Operating ambient temperature 範囲
    -40 °C～125 °C
  • Output resolution
    14 Bit (accumulated)
  • Sensing channels
    10
  • Shielding possibility
    for cable and PCB
  • System sensitivity
    80 fF/LSB
  • パッケージ寸法
    8.2 x 1.86 x 7.8 mm
  • 機能
    human presence detection, fluid level / quality sensing
  • 診断
    Error monitoring
  • 車載用認定品
    AEC-Q100
  • 電源電圧
    5 V
OPN
製品ステータス
インフィニオン パッケージ
パッケージ名
梱包サイズ
梱包形態
MSL (湿度感受性レベル)
防湿梱包
鉛フリー
ハロゲンフリー
RoHS対応
Infineon stock last updated:
The AS8579 is a capacitive sensor that detects the change of capacity in different automotive applications.The capacitive sensor measures the impedance using the most reliable measurement principle. It can be used for capacitive touch & proxmity detection and fluid level measurements.

特長

  • I/Q-Signal demodulation
  • 10 independent measurements (10 SEN lines)
  • VAR+FIX_SEN function to avoid parasitics
  • Designed according functional safety standard
  • AEC-Q100 Grade 1 qualified

利点

  • Accurate capacitive measurement (seperation of resistive and capacitive information)
  • Higher durability and lower system costs
  • Enabler for safety critical applications
  • Suitable for automotive applications
