AS5900

AS5900

128-channel low noise current-to-digital converter
データシート

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

AS5900
AS5900
データシート


製品仕様情報

  • Input channels
    128
  • Input related noise
    0.51
  • Integration time
    50 µs
  • Power consumption per channel (最小)
    1 mW
  • Resolution
    26 bit
  • 機能
    x-ray sensing

OPN
製品ステータス
インフィニオン パッケージ
パッケージ名
梱包サイズ
梱包形態
MSL (湿度感受性レベル)
防湿梱包
鉛フリー
ハロゲンフリー
RoHS対応
The AS5900 device is a low noise, 128-channel current-to-digital converter that enables the readout of the photodiodes. Its 128-low-noise and high linear converter channels provide an increased gray scale, improved contrast and reduce artifacts of 3D CT images. The low power consumption of 1mW per channel reduces self-heating effects and the overall power consumption of the system.

特長

  • Flexible configuration
  • Adjustable range, resolution, speed and power
  • High speed LVDS data interface
  • Voltage reference and temperature sensor

利点

  • Ultra-low noise down to 3200 electrons for a full-scale range up to 1µA
  • Very fast integration time down to 50µs
  • High linearity of ±250ppm of reading ±1ppm of FSR
  • Very low power dissipation down to 1mW/channel
  • Up to 26-bit resolution
