AS5262

AS5262

Redundant 12-bit rotary position sensor with linear analog output and overvoltage protection
データシート

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

AS5262
AS5262
データシート


製品仕様情報

  • Accurancy
    0.5 °
  • Die in package
    dual
  • Operating ambient temperature 範囲
    -40 °C～150 °C
  • Output interface
    analog linear
  • Resolution
    12 bit
  • 技術
    magnetic
  • 機能
    on-axis angle position sensing
  • 車載用認定品
    AEC-Q100
  • 電源電圧
    5 V

OPN
製品ステータス
インフィニオン パッケージ
パッケージ名
梱包サイズ
梱包形態
MSL (湿度感受性レベル)
防湿梱包
鉛フリー
ハロゲンフリー
RoHS対応
The AS5262 is a redundant, contactless Hall-based magnetic position sensor for very accurate angular measurement over a full turn of 360°. It is a compact integrated solution which provides the absolute angle measurement with a resolution of 0.09° over a full revolution as analog ratiometric output signal. The internal 14-bit core of the AS5162 enables a fine programming of the start and stop positions with a resolution of 0.02°.

特長

  • Resolves smaller angular excursions
  • Programmable start and end point
  • Saw tooth mode 1-4 slopes per revolution
  • Clamping levels
  • Transition point
  • Broken GND and VDD detection for all loads
  • Analog output ratiometric to VDD
  • Wide temperature range: - 40°C to 150°C
  • Small Pb-free package: MLF 16 6x6 (w/ dimple)

利点

  • Great flexibility on angular excursion
  • Simple programming
  • Failure diagnostics
  • High-resolution output signal
  • Stacked die redundant approach
