10-bit magnetic position sensor with digital angle (interface) output
データシート

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

AS5050A
AS5050A
データシート


製品仕様情報

  • Accurancy
    0.5 °
  • Die in package
    single
  • Operating ambient temperature 範囲
    -40 °C～85 °C
  • Output interface
    SPI
  • Resolution
    10 bit
  • 技術
    magnetic
  • 機能
    on-axis angle position sensing
  • 電源電圧
    3.3 V

OPN
製品ステータス
インフィニオン パッケージ
パッケージ名
梱包サイズ
梱包形態
MSL (湿度感受性レベル)
防湿梱包
鉛フリー
ハロゲンフリー
RoHS対応
The AS5050A is a 10-bit rotary position sensor for absolute angular measurement over a full turn of 360° based on contactless magnetic sensor technology. This device fits perfectly for on-axis applications where a simple 2-pole magnet rotates above or below the sensor IC. The absolute magnet angular position is measured with a resolution of 10 bit = 1024 positions per revolution and it is provided as a digital value on the serial interface (SPI).

特長

  • Contactless abs. angle position measurement
  • Very low standby current
  • Very small package
  • Immune to external magnetic stray fields

利点

  • Highest reliability and durability in harsh environments
  • Sensor for battery operated devices
  • Lower material cost (no magnetic shielding needed)
