OptiMOS™ 5

Leading MOSFET silicon technology combined with robust packaging to deliver best-in-class performance and outstanding current capacity

link

About

OptiMOS™ 5 benefits

The OptiMOS™ 5 family of MOSFETs features high-performance MOSFETs by combining leading-edge silicon technology along with packaging innovation.

The benefits of this family includes:

  • High system efficiency
  • Less paralleling
  • Increased power density
  • Very low voltage overshoot
  • Low switching losses
  • Reduced snubber circuit needed
  • System cost reduction
  • Improvements in EMI
  • Improved commutation ruggedness

OptiMOS™ 5 product portfolio

The OptiMOS™ 5 power MOSFET family is available in voltage ranges from 25 V to 150 V with a wide variety of package options.

The package options includes:

  • TO-220
  • TO-220 FullPAK
  • TO-Leadless (TOLL)
  • SuperSO8 (5x6)
  • PQFN 3.3x3.3
  • PQFN 2x2
  • D2PAK 7-pin
  • D2PAK and
  • DPAK

OptiMOS™ 5 target applications

The OptiMOS™ 5 MOSFET voltage node is optimized for the intended application. The OptiMOS™ 5 40 V and 60 V MOSFETs are optimized for synchronous rectification with low Rds(on), low FOMg and include a schottky-like body diode.

The OptiMOS™ 5 150 V family offers best-in-class Rds(on), Qg and Qgd as well as superior Qrr for improved EMI behavior.

Target applications include:

  • SMPS: AC-DC converters, adapters, chargers, offline power supplies, LCD TV's, PC power, server and telecom
  • Inverters and battery powered: Solar, BPA, Industrial drives, multicopter and power tools.
