PSOC™ 63 Bluetooth® LE MCU

Industry's first dual-core Bluetooth® LE MCU for ultra-low power, ML-ready IoT applications

anchor

Overview

PSOC™ is the world’s first programmable embedded design platform. The PSOC™ 63 Bluetooth® Low Energy (LE) MCU includes dual-core 150 MHz Arm® Cortex®-M4 and 100 MHz Arm® Cortex®-M0+ processors, offering highest compute capability, optimized for AI/ML edge applications. It offers best-in-class ultra-low-power, flexibility, and security for your IoT applications.

Key Features

  • 150/100 MHz Arm® Cortex®-M4/M0+
  • Bluetooth® LE
  • Up to 1 MB flash and 288 KB SRAM
  • 1.7 to 3.6 V supply voltage range
  • ~40° to 85°C operating temperature range
  • Pre-certified modules
  • CAPSENSE™ capacitive sensing
  • ML and graphics support
  • Programmable analog/digital blocks
  • Up to 84 programmable GPIOs
  • Rich MCU peripherals
  • Built-in security

Products

About

High compute capability optimized for AI/ML edge applications

Infineon offers PSOC™ 63 MCU with AIROC™ Bluetooth® Low Energy (LE) to drive your low-power IoT devices. It has dual-core 150 MHz Arm® Cortex®-M4 and 100 MHz Arm® Cortex®-M0+ processors, offering industry’s highest compute capability, optimized for AI/ML edge applications.

PSOC™ 63 MCU with AIROC™ Bluetooth® LE integrates programmable analog front ends, industry-leading CAPSENSE™ touch sensing user interface, and Bluetooth® LE radio. It includes a royalty-free Bluetooth® LE protocol stack compatible with Bluetooth® 5.4.

PSOC™ 63 with AIROC™ Bluetooth® LE MCU supports rich configurable MCU peripherals with 84 programmable GPIOs and six overvoltage-tolerant capable pins, making it suitable for a wide range of IoT applications.

This MCU is supported in the ModusToolbox™ software and tools with an extensive range of libraries including graphics, Machine Learning, CAPSENSE™-based HMI and code examples. This helps you to deliver high-quality, differentiated products to market on time.

PSOC™ 63 Bluetooth® LE MCU module

For faster time to market, Infineon offers PSOC™ 63-based CYBLE-416045-02 module which is fully certified, Bluetooth® qualified, and easy to integrate into your IoT designs.

Learn more about CYBLE-416045-02 module
Focus applications for PSOC™ 63 Bluetooth® LE MCU module

Some of our focus applications use cases include:

Certified Bluetooth® LE SoCs and modules

With an extensive experience in delivering certified Bluetooth® LE SoCs and modules, Infineon’s regulatory testing and certification process is precise and rigorous.

Infineon’s PSOC™ 63 with AIROC™ Bluetooth® LE MCU and modules are qualified by Bluetooth® SIG, and include regulatory certification approval for FCC, ISED, MIC, and CE. This allows you to focus on creating unique IoT applications without having to deal with the complexities associated with complicated board bring up, RF/specification testing, performance testing, and regulatory testing.

Ease of use

PSOC™ 6 is supported by ModusToolbox™, a unified ecosystem platform with tools and software solutions. ModusToolbox™ Software is a modern, extensible development ecosystem. Provided as a collection of development tools, libraries, and embedded runtime assets, ModusToolbox™ Software is architected to provide a flexible and comprehensive development experience. ModusToolbox™ Software supports industry standard toolchains and development tools like Eclipse IDE, Microsoft Visual Studio Code, IAR Embedded Workbench, Arm µVision. Various compiler options (GNU, IAR, Arm). PSOC™ 6 is also supported by DEEPCRAFT™ Studio for developing Edge AI models.

ModusToolbox™ Software
DEEPCRAFT™ Studio
Digital Documentation
Out of Box Web Experience

High compute capability optimized for AI/ML edge applications

Infineon offers PSOC™ 63 MCU with AIROC™ Bluetooth® Low Energy (LE) to drive your low-power IoT devices. It has dual-core 150 MHz Arm® Cortex®-M4 and 100 MHz Arm® Cortex®-M0+ processors, offering industry’s highest compute capability, optimized for AI/ML edge applications.

PSOC™ 63 MCU with AIROC™ Bluetooth® LE integrates programmable analog front ends, industry-leading CAPSENSE™ touch sensing user interface, and Bluetooth® LE radio. It includes a royalty-free Bluetooth® LE protocol stack compatible with Bluetooth® 5.4.

PSOC™ 63 with AIROC™ Bluetooth® LE MCU supports rich configurable MCU peripherals with 84 programmable GPIOs and six overvoltage-tolerant capable pins, making it suitable for a wide range of IoT applications.

This MCU is supported in the ModusToolbox™ software and tools with an extensive range of libraries including graphics, Machine Learning, CAPSENSE™-based HMI and code examples. This helps you to deliver high-quality, differentiated products to market on time.

PSOC™ 63 Bluetooth® LE MCU module

For faster time to market, Infineon offers PSOC™ 63-based CYBLE-416045-02 module which is fully certified, Bluetooth® qualified, and easy to integrate into your IoT designs.

Learn more about CYBLE-416045-02 module

Focus applications for PSOC™ 63 Bluetooth® LE MCU module

Some of our focus applications use cases include:

Certified Bluetooth® LE SoCs and modules

With an extensive experience in delivering certified Bluetooth® LE SoCs and modules, Infineon’s regulatory testing and certification process is precise and rigorous.

Infineon’s PSOC™ 63 with AIROC™ Bluetooth® LE MCU and modules are qualified by Bluetooth® SIG, and include regulatory certification approval for FCC, ISED, MIC, and CE. This allows you to focus on creating unique IoT applications without having to deal with the complexities associated with complicated board bring up, RF/specification testing, performance testing, and regulatory testing.

Ease of use

PSOC™ 6 is supported by ModusToolbox™, a unified ecosystem platform with tools and software solutions. ModusToolbox™ Software is a modern, extensible development ecosystem. Provided as a collection of development tools, libraries, and embedded runtime assets, ModusToolbox™ Software is architected to provide a flexible and comprehensive development experience. ModusToolbox™ Software supports industry standard toolchains and development tools like Eclipse IDE, Microsoft Visual Studio Code, IAR Embedded Workbench, Arm µVision. Various compiler options (GNU, IAR, Arm). PSOC™ 6 is also supported by DEEPCRAFT™ Studio for developing Edge AI models.

ModusToolbox™ Software
DEEPCRAFT™ Studio
Digital Documentation
Out of Box Web Experience
