Transmission speed sensors

XENSIV™ transmission sensors for highly accurate speed and direction sensing in pole wheel and steel wheel applications

Overview

Infineon's XENSIV™ transmission speed sensors use ferromagnetic gear teeth or encoder targets to measure linear or rotational speed via contactless magnetic sensing, delivering a clear output signal. Tailored for automotive safety and powertrain, they integrate capacitors for superior EMC robustness and strong ESD protection. All are AEC-Q100 and partially ISO 26262 qualified, while also excelling in harsh industrial environments with low jitter.

Key Features

  • Top & side readout variants
  • Duty cycle / multiple PWM protocols
  • High EMC robustness
  • Premium TMR low-jitter output
  • Active vibration suppression
  • Variants for large air gaps
  • For various pole & steel wheels
  • Supports all common tooth wheels
  • Functional safety options available
  • 2-wire or 3-wire interfaces
  • High magnetic stray field robustness
  • SmCo, NdFeB & ferrite magnet options
Please choose a valid product table template page

Products

Hall-based transmission sensors for accurate speed & direction sensing

The XENSIV™ TLE4953/55 is a family of differential Hall effect sensors housed in a "Plastic Green Single Small Outline" package, with a 2-wire current interface (PG-SSO-2). These sensors are automotive AEC-Q100 qualified, with a high-temperature operating range.

TLE4953 key facts

  • 5000 h at 150°C operating temperature with limited peaks above
  • First-generation transmission sensor featuring an integrated capacitor
  • High resistance to piezo effects

TLE4955 key facts

  • 2500 h at 175°C operating temperature with limited peaks above
  • Next-generation transmission sensor with integrated capacitor for long-lasting supply
  • Variant for wheels with large pitches available
  • Large operating air gap capability

The XENSIV™ TLE4953/55 sensors are well-suited for both pole wheel and steel wheel applications.

Hall-based transmission sensors for accurate speed & direction sensing

The XENSIV™ TLE4959 is a family of differential Hall effect transmission sensors housed in a "Plastic Green Single Small Outline" package, with a 3-wire voltage interface (PG-SSO-3). These sensors are automotive AEC-Q100 qualified, covering the highest operating temperature profiles (2500 h at 175°C with limited peaks up to 185°C)

TLE4959 key facts

  • Duty cycle and multiple PWM variants available
  • Large operating air gap capability
  • Trimmed for rare earth magnets (SmCo, NdFeB)

The XENSIV™ TLE4959 sensors are well-suited for both pole wheel and steel wheel applications.

ISO 26262-compliant TMR transmission sensors for speed/direction sensing

The XENSIV™ TLE5555 is a family of highly sensitive differential TMR-based transmission sensors housed in a "Plastic Green Single Small Outline" package, with a 2-wire current interface (PG-SSO-2). These sensors are automotive AEC-Q100 qualified, covering the highest operating temperature profiles (2500 h at 175°C with limited peaks up to 185°C)

Transmission TMR generation combining advantages from Hall and GMR technologies.

High magnetic field sensitivity enables ultra-low jitter over a high operating air gap range.

All sensors meet ASIL B metrics and are developed according to ASIL D requirements.

TLE5555IC series key facts

  • Optimized for steel wheels
  • Top and side read variants available
  • Multiple PWM protocol variants available
  • Variant with direction detection on or off available

TLE5555ICB series key facts

  • Features an integrated backbias magnet
  • Available upon request only

TLE5555IC ME series key facts

  • Optimized for pole wheels
  • Top and side read capable (combined in one device)
  • Multiple PWM protocol variants available
  • Variant with direction detection on or off available
Hall-based transmission sensors for accurate speed & direction sensing

The XENSIV™ TLE4953/55 is a family of differential Hall effect sensors housed in a "Plastic Green Single Small Outline" package, with a 2-wire current interface (PG-SSO-2). These sensors are automotive AEC-Q100 qualified, with a high-temperature operating range.

TLE4953 key facts

  • 5000 h at 150°C operating temperature with limited peaks above
  • First-generation transmission sensor featuring an integrated capacitor
  • High resistance to piezo effects

TLE4955 key facts

  • 2500 h at 175°C operating temperature with limited peaks above
  • Next-generation transmission sensor with integrated capacitor for long-lasting supply
  • Variant for wheels with large pitches available
  • Large operating air gap capability

The XENSIV™ TLE4953/55 sensors are well-suited for both pole wheel and steel wheel applications.

Hall-based transmission sensors for accurate speed & direction sensing

The XENSIV™ TLE4959 is a family of differential Hall effect transmission sensors housed in a "Plastic Green Single Small Outline" package, with a 3-wire voltage interface (PG-SSO-3). These sensors are automotive AEC-Q100 qualified, covering the highest operating temperature profiles (2500 h at 175°C with limited peaks up to 185°C)

TLE4959 key facts

  • Duty cycle and multiple PWM variants available
  • Large operating air gap capability
  • Trimmed for rare earth magnets (SmCo, NdFeB)

The XENSIV™ TLE4959 sensors are well-suited for both pole wheel and steel wheel applications.

ISO 26262-compliant TMR transmission sensors for speed/direction sensing

The XENSIV™ TLE5555 is a family of highly sensitive differential TMR-based transmission sensors housed in a "Plastic Green Single Small Outline" package, with a 2-wire current interface (PG-SSO-2). These sensors are automotive AEC-Q100 qualified, covering the highest operating temperature profiles (2500 h at 175°C with limited peaks up to 185°C)

Transmission TMR generation combining advantages from Hall and GMR technologies.

High magnetic field sensitivity enables ultra-low jitter over a high operating air gap range.

All sensors meet ASIL B metrics and are developed according to ASIL D requirements.

TLE5555IC series key facts

  • Optimized for steel wheels
  • Top and side read variants available
  • Multiple PWM protocol variants available
  • Variant with direction detection on or off available

TLE5555ICB series key facts

  • Features an integrated backbias magnet
  • Available upon request only

TLE5555IC ME series key facts

  • Optimized for pole wheels
  • Top and side read capable (combined in one device)
  • Multiple PWM protocol variants available
  • Variant with direction detection on or off available
