Summary

The Arm® Cortex®-M23 based MOTIX™ TLE99xx SoC/SiP solutions from Infineon enable efficient and safe BDC and BLDC motor control. Integrating the microcontroller, power supply, LIN transceiver, driver stage and optional MOSFETs on a single chip (SoC) or in one package (SiP), they deliver ultra-compact designs. ISO 26262-compliant and automotive-qualified, the TLE99xx family ensures uncompromising reliability for automotive applications such as pumps, fans, valves and seat systems. A comprehensive ecosystem of documentation, software, tools and design-in partners supports all products.

Please choose a valid product table template page

Products

About

Why choose the Arm® Cortex®-M23 based MOTIX™ TLE99xx motor control system solutions?

  • A highly integrated system solution minimizes PCB design and reduces design effort for streamlined development.
  • High integration enables significant BOM savings by eliminating the need for discrete components.
  • Comprehensive support ecosystem ensures ease of use by providing essential tools, software, reference designs, technical documentation and a wide network of partners.
  • Platform-based development approach enables software synergies.
  • Expanded portfolio offers tailored solutions to address diverse customer requirements and specific application needs.
View our Arm® Cortex®-M23 portfolio

What are the characteristics of the Arm® Cortex®-M23 based MOTIX™ TLE99xx family?

  • 32-bit Arm® Cortex®-M23 core at up to 40 MHz
  • On-chip clock generation
  • CRC engine for data integrity
  • Flash memory up to 72 KB with EEPROM emulation; RAM up to 6 KB
  • 10x 16-bit timer (GPT12 and CCU7), 1x 24-bit timer (SYSTICK)
  • Fast synchronous communication interface (SSC)
  • Temperature range TJ : -40°C up to 175°C
  • Arm® TrustZone® enabling software isolation between secure and non-secure domains



What applications is the Arm® Cortex®-M23 based MOTIX™ TLE99xx family best suited for?

The Arm® Cortex®-M23 based MOTIX™ TLE99xx family is engineered to deliver ultra-compact, efficient solutions for small- to medium-sized BDC and BLDC motor control applications across automotive and industrial sectors.

Specifically tailored for Automotive Thermal Management applications, including pumps, fans, HVAC blowers, expansion valves, coolant valves, and grill shutters, as well as Automotive Comfort & Convenience applications such as seat control, window lifts, sunroofs, and wipers.

Comprehensive development toolchain for the Arm® Cortex®-M23 based MOTIX™ TLE99xx family

Arm® Cortex®-M23 based MOTIX™ TLE99xx family is supported by a complete development toolchain provided by Infineon and third-party vendors, including compilers, debuggers, evaluation boards, low-level drivers, configuration tools, and a variety of example software code.

Download getting started guide

What software components are available for BLDC motor control?

  • Advanced FOC Motor Control

Achieve exceptional motor control solutions tailored for automotive applications like pumps and fans. Our FOC (Field-Oriented Control) motor control library is equipped with advanced drive algorithms, such as CWA closed-loop start, wind-milling, and field weakening, to enhance efficiency and functionality.

  • Free Evaluation and Intuitive Tools

Our MOTIX™ Solution Designer (LINK Available?) offers various FOC motor control examples build from the library and supports in SW parametrization, runtime evaluation, tracing, and tuning.

  • Automotive-Grade Quality with Licensing Options

Benefit from Automotive SPICE-qualified motor control software available for licensing from MOTEON. Developed with industry-leading quality standards, this software guarantees reliability and compliance for productive automotive use.

  • Block Commutation Solutions

For engineers seeking block commutation motor control, take advantage of solutions built around MOTIX™ TLE995x and MOTIX™ TLE993x devices supporting both 6-step and 12-step configurations with Back Electromotive Force (BEMF) zero-crossing detection. As with our FOC library, free evaluation versions are available through the Infineon Developer Center (IDC).

Infineon Developer Center
More about MOTIX™ Software & Tools

Secure your designs with a strong and reliable partner

Infineon delivers robust, rigorously tested components engineered to last and perform in any condition. Driven by continuous innovation and agile, efficient manufacturing, we ship high-quality solutions fast to keep you ahead of the competition.

Product availability you can count on.

Infineon’s Longevity Program
