Active and preferred
RoHS Compliant

SLM37EMA1M0

package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

SLM37EMA1M0
SLM37EMA1M0

Product details

  • Ambient Temperature
    -40 °C to 105 °C
  • Asymmetric Cryptography
    ECC/RSA, AES/DES
  • Certifications
    CC EAL6+ high
  • CPU
    32-bit
  • Delivery Forms
    MFF2, sawn wafer
  • Interfaces
    ISO 7816, GPIO, SPI, SWP, I2C
  • Leading Technologies
    SOLID FLASH™
  • NVM / 凌捷掩膜
    1000 kByte
  • Product Description
    Security cryptocontroller, optimized for industrial applications (M2M SIM and eSIM)
  • RAM
    48 kByte
Recommended
OPN
SLM37EMA1M0CX1SA1
Product Status active and preferred active and preferred
Infineon Package
PG-VQFN-8
--
Package Name N/A N/A
Packing Size 3000 1
Packing Type TAPE & REEL WAFER SAWN
Moisture Level N/A N/A
Moisture Packing NON DRY DRY
Lead-free No Yes
Halogen Free Yes Yes
RoHS Compliant Yes Yes
Infineon stock last updated:

Product Status
Active
Infineon Package
PG-VQFN-8
Package Name -
Packing Size 3000
Packing Type TAPE & REEL
Moisture Level -
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant

Product Status
Active
Infineon Package --
Package Name -
Packing Size 1
Packing Type WAFER SAWN
Moisture Level -
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
The SLM37 family, with up to 2 MB of NVM and its CC EAL6+ certification, provides you with a new class of performance and security levels for your eSIM and embedded secure elements functionality, which can be extended to support crypto toolbox and in-the-field updates. The SLM37EMA1M0 has 1 MB of NVM and multiple interfaces, including SPI.

Features

  • 32-bit CPU
  • 1 MB SOLID FLASH™
  • Asymmetric (ECC/RSA) cryptography
  • Symmetric (AES/DES) cryptography
  • GPIO, ISO 7816, I2C, SPI, SWP interfaces
  • Industrial grade ( -40° to 105°C)
  • CC EAL6+ high
  • 48 kB RAM

Applications
