ISC024N08NM7
Active and preferred
RoHS Compliant

ISC024N08NM7

OptiMOS™ 7 n-channel power MOSFET 80 V in SSO8 package
Data Sheet
package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

ISC024N08NM7
ISC024N08NM7
Data Sheet

Product details

  • ID (@25°C) max
    167 A
  • Operating Temperature range
    -55 °C to 175 °C
  • Package
    SuperSO8 5x6
  • Polarity
    N
  • QG (typ @10V)
    49 nC
  • RDS (on) (@10V) max
    2.4 mΩ
  • VDS max
    80 V
  • VGS(th) range
    2.3 V to 3.2 V
  • VGS(th)
    2.8 V
Recommended
OPN
ISC024N08NM7ATMA1
Product Status active and preferred
Infineon Package
PG-TDSON-8
Package Name SuperSO8 FL
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead-free No
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package
PG-TDSON-8
Package Name SuperSO8 FL
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
OptiMOS™ 7 80 V is the latest technology setting a new industry standard for a perfect balance of power efficiency and performance with cost efficiency.

Features

  • High performance silicon technology
  • Normal level gate drive
  • 175°C rated
  • Industrial qualification

Benefits

  • >32% Improved FOMs compared to OptiMOS™ 5
  • Improved switching performance compared to OptiMOS™ 5
  • Ease of use
  • Soft body diode
  • Robust reliable performance
