CY62177G30-55ZXI

32Mb, x16, 3.0V, MoBL™ SRAM Ind, TSOP-48
Data Sheet
package
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CY62177G30-55ZXI
CY62177G30-55ZXI
ea.
Data Sheet

Product details

  • Density
    32 MBit
  • Family
    MoBL™ SRAM
  • Interfaces
    Parallel
  • Lead Ball Finish
    Pure Sn
  • Operating Temperature
    -40 °C to 85 °C
  • Operating Voltage
    2.2 V to 3.6 V
  • Organization (X x Y)
    2M x 16
  • Peak Reflow Temp
    260 °C
  • Currently planned availability until at least
    2033
  • Qualification
    Industrial
Recommended
OPN
CY62177G30-55ZXI
Product Status active and preferred
Infineon Package
PG-TSOP-48
Package Name TSOP-I-48 (51-85183)
Packing Size 96
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-TSOP-48
Package Name TSOP-I-48 (51-85183)
Packing Size 96
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
Infineon's 32Mb density Ultra-Low-Power (ULP) SRAM with on-chip ECC offers high-performance and reliability for mission-critical industrial systems. With an industry-leading standby current of 19µA at +85°C, it ensures best-in-class battery lifetimes. This high-capacity parallel interface asynchronous SRAM, based on 65-nm technology, features embedded ECC and bit-interleaving, providing freedom from soft errors with < 0.1 FITs/Mbit.

Features

  • 32Mbit SRAM, 2Mx16
  • High-speed parallel bus
  • 55ns access time
  • Operating voltage: 2.2-3.6V
  • Ultra-low-power standby
  • Embedded ECC
  • 1.5V data retention
  • RoHS-compliant 48-pin TSOP (I)

Benefits

  • Low-power battery-backed datalogging
  • Freedom from soft errors
  • Compatible with lower density SRAMs
  • Drop-in legacy SRAM compatibility

Applications
