CY62128ELL-55ZAXET
Active and preferred
RoHS Compliant

CY62128ELL-55ZAXET

Datasheet
package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CY62128ELL-55ZAXET
CY62128ELL-55ZAXET
Datasheet

Product details

  • Density
    1 MBit
  • Family
    MoBL™ SRAM
  • Interfaces
    Parallel
  • Lead Ball Finish
    Pure Sn;Ni/Pd/Au
  • Operating Temperature range
    -40 °C to 125 °C
  • Operating Voltage (VCCQ) max
    5.5 V
  • Operating Voltage range
    4.5 V to 5.5 V
  • Organization (X x Y)
    128K x 8
  • Peak Reflow Temp
    260 °C
  • Qualification
    Automotive
  • Speed
    55 ns
Recommended
OPN
CY62128ELL-55ZAXET
Product Status active and preferred
Infineon Package
PG-TSOP-32
Package Name STSOP-32 (51-85094)
Packing Size 1500
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead-free No
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package
PG-TSOP-32
Package Name STSOP-32 (51-85094)
Packing Size 1500
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
CY62128ELL-55ZAXET is a 1-Mbit (128 K × 8) CMOS SRAM for Automotive-E designs, specified for 55 ns access. It runs from 4.5 V to 5.5 V and interfaces to processors with TTL input levels (not CMOS). Typical active current is 1.3 mA at 1 MHz and 11 mA at fmax, with automatic CE power-down standby typically 1 µA (30 µA max). Data I/O is 8-bit with high-Z outputs when deselected. Available in a 32-pin Pb-free STSOP (ZA).

Features

  • 128K × 8 SRAM organization
  • 45 ns read cycle time (tRC)
  • 4.5 V to 5.5 V VCC operation
  • 1.3 mA typ ICC at 1 MHz
  • 1 µA typ standby current
  • Auto CE power-down (ISB2)
  • CE1/CE2 and OE chip controls
  • High-Z outputs when deselected
  • TTL-compatible input levels
  • VIH 2.2 V, VIL 0.8 V thresholds
  • 10 pF max input capacitance
  • tDOE 22 ns OE to data valid

Benefits

  • Fast 45 ns cycles cut latency
  • 5 V supply fits legacy designs
  • 1.3 mA typ lowers active power
  • 1 µA standby extends battery life
  • Auto power-down saves idle energy
  • CE1/CE2 simplify memory expansion
  • High-Z outputs ease bus sharing
  • TTL levels ease MCU/CPU interface
  • Defined thresholds reduce errors
  • Low capacitance eases timing margins
  • 22 ns OE read improves response
  • Lower standby cuts thermal load
