XMC4400-F100F512 BA

Data Sheet
package
board
Multiple OPNs available
ea.

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

XMC4400-F100F512 BA
XMC4400-F100F512 BA
ea.
Data Sheet

Product details

  • A/D Input Lines
    18
  • Additional Features
    USB, Ethernet 10/100 Mbit/s, HRPWM
  • Budgetary Price €/1k
    6.07, 6.07
  • CAN Nodes
    2
  • CPU
    ARM Cortex-M4
  • Digital I/O Pins
    75
  • DMA Channels
    8
  • DSP Functionality
    yes
  • EEPROM Emulation
    Yes
  • External Bus Interface
    no
  • Family
    XMC4400
  • Flash
    512 kByte
  • Floating Point Unit
    yes
  • Frequency max
    120 MHz
  • I/O Operation Voltages
    3.3 V
  • Instruction Width ([bits])
    32/16
  • On-chip Clock Generation
    yes
  • On-chip Voltage Regulator
    yes
  • Oscillator Watchdog
    yes
  • Power Mode
    clock gating possible
  • Program Memory
    512 kByte
  • Qualification
    Industrial
  • Real Time Clock
    yes
  • Secondary Core
    N/A
  • Serial I/O Interfaces
    4
  • SRAM (incl. Cache)
    80 kByte
  • SRAM
    80 kByte
  • Temperature
    -40 to 85°C
  • Timed I/O Pins
    32
  • Touch/LED Matrix Control
    yes
  • Type of Memory
    Flash
  • Type of Serial I/O Interfaces
    I²C, I²S, SPI, UART
  • Watchdog Timer
    yes
Recommended
OPN
XMC4400F100F512BAXQMA1 XMC4400F100F512BAXUMA1
Product Status active and preferred active and preferred
Infineon Package
PG-LQFP-100
PG-LQFP-100
Package Name N/A N/A
Packing Size 540 1000
Packing Type TRAY TAPE & REEL
Moisture Level 3 3
Moisture Packing DRY DRY
Lead-free Yes Yes
Halogen Free Yes Yes
RoHS Compliant Yes Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-LQFP-100
Package Name -
Packing Size 540
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock

Product Status
Active
Infineon Package
PG-LQFP-100
Package Name -
Packing Size 1000
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
XMC4400 combines Infineon's leading-edge peripheral set with an industry-standard ARM® Cortex™-M4. As one of its key features it offers a high-resolution PWM unit with a tiny resolution of 150ps. This unique peripheral makes it especially suitable for digital power conversion in applications like solar inverters ,SMPS and uninterruptible power supplies (UPS). XMC4400 is supported by Infineon's integrated development platform DAVE™ 3.

Features

  • ARM® Cortex®-M4 120MHz , DSP MAC & FPU
  • 8-channel DMA + DMAs for USB & Ethernet
  • USIC4ch [Quad SPI, SCI/UART,I²C,I²S,LIN]
  • Supply voltage range: 3.13 - 3.63V
  • USB 2.0 full-speed on-the-go
  • CPU Frequency: 120MHz
  • Peripherals Clock: 120 [MHZ]
  • eFlash: 512kB including hardware ECC
  • 80kB SRAM
  • 10/100 Ethernet MAC (/w IEEE 1588)
  • 2x CAN, 64 MO
  • Package: PG-LQFP-100
