TLE9867QXW20

The MOTIX™ TLE9867QXW20 is qualified up to 175°C and can be used for actuator drives
Data Sheet
package
board
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

TLE9867QXW20
TLE9867QXW20
ea.
Data Sheet

Product details

  • Clock Frequency max
    24 MHz
  • Family
    MOTIX™ 32-bit motor control SoC
  • Frequency
    24 MHz
  • GPIO
    10
  • High Side Switch
    0
  • High Voltage Monitor Input
    1
  • Instruction Set Architecture
    Arm® Cortex®-M3
  • Interfaces
    PWM + LIN
  • Language
    SPICE
  • Low Side Switch
    0
  • MOSFET Drivers (High Side)
    2
  • MOSFET Drivers (Low Side)
    2
  • Operating Voltage
    5.5 V to 28 V
  • Operational Amplifier
    Yes
  • Currently planned availability until at least
    2038
  • PN MOS DRIVER
    No
  • Product Category
    Microcontroller (MCU)
  • RAM
    6 kByte
  • Solid Flash
    64 kByte
  • Technology
    MOTIX™ MCU (SoC)
  • Temperature
    - 40°C - 175°C
  • Tj max
    175 °C
Recommended
OPN
TLE9867QXW20XUMA1
Product Status active and preferred
Infineon Package
PG-VQFN-48
Package Name N/A
Packing Size 2500
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-VQFN-48
Package Name -
Packing Size 2500
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
The MOTIX™ TLE9867QXW20 is a single-chip H-Bridge motor control solution that combines an Arm® Cortex®-M3 core, flash memory, analog and mixed-signal peripherals, a LIN transceiver, and driving stages in a single package. This compact Grade 0 device is designed to address the specific needs of space- and cost-critical automotive DC motor control applications, such as sunroof and power window lift.

Features

  • 32-bit Arm® Cortex®-M3 up to 24 MHz
  • Single power supply from 5.5 V to 28 V
  • On-chip oscillator and PLL for clock
  • 64 KB flash, 6 KB RAM, EEPROM emu
  • Integrated LIN transceiver
  • High voltage monitoring pin (MON)
  • Fast synchronous communication (SSC)
  • Two-phase bridge driver (BDRV)
  • Low-side shunt current sense amplifier
  • 8-bit and 10-bit ADCs
  • Temperature range: -40°C to 175°C
  • Compact VQFN-48 package

Benefits

  • Best-in-class device
  • Optimized BOM cost
  • Compact dimensions
  • Premium design-in experience
