TLE4942-1C

XENSIV™ - TLE4942-1C Hall effect sensor with two-wire PWM current interface
Data Sheet
package
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

TLE4942-1C
TLE4942-1C
ea.
Data Sheet

Product details

  • Applications
    ABS/Transmission
  • Budgetary Price €/1k
    0.9, 0.9
  • C Package Available
    yes
  • Classification
    ISO 26262-ready
  • Direction Detection
    yes
  • Interfaces
    Current
  • Currently planned availability until at least
    2033
  • Technology
    Hall
  • Type of Hysteresis
    hidden fixed
Recommended
OPN
TLE49421CHAMA2
Product Status active and preferred
Infineon Package
PG-SSO-2
Package Name N/A
Packing Size 1500
Packing Type AMMO-PACK
Moisture Level NA
Moisture Packing NON DRY
Lead-free Yes
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-SSO-2
Package Name -
Packing Size 1500
Packing Type AMMO-PACK
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
Infineon XENSIV™ TLE4942-1C: Hall effect sensor for vehicle dynamics & ABS. Provides speed, direction & assembly position. Two-wire current interface (PWM), no external components needed. High accuracy & sensitivity for harsh automotive conditions. BiCMOS technology enables integration. Optimized compensation for easy manufacturing. Includes overmolded 1.8 nF capacitor for improved EMI performance.

Features

  • Two-wire PWM current interface
  • Detection of rotation direction
  • Air gap diagnosis
  • Assembly position diagnosis
  • Dynamic self-calibration principle
  • Single chip solution
  • High sensitivity
  • South &north pole pre-induction possible
  • High resistance to piezo effects
  • Large operating air gaps
  • Wide operating temperature range

Applications
