TCA505B
TCA505B
Data Sheet

Product details

OPN
Product Status
Infineon Package
Package Name
Packing Size
Packing Type
Moisture Level
Moisture Packing
Lead-free
Halogen Free
RoHS Compliant
Infineon stock last updated:
Besides its basic functions (oscillator, demodulator and threshold switch), the bipolar monolithic IC TCA505B includes a number of useful extra functions that enable high-grade, inductive proximity switches to be designed for an attractive price/performance ratio and with space savings. Compared to earlier ICs for inductive proximity switches temperature drift, noise immunity and the switching frequency of the IC have been improved.

Features

  • Wide supply voltage
  •  Low current consumption of less than 0 mA
  •  Integrated output stage for up to 60 mA output current
  •  Shortcircuit and overload protection of output stages and external components
  •  Temperature response of the IC compensates that of the coil
  •  High noise immunity
  •  High switching frequencies up to 5 kHz
  •  Useful extra functions
  •  Suitable for twowire AC proximity switches
  •  Temperature range  40 to 110 degC
