Active and preferred

RIC70847F

Rad hard 17.1 V buck controller with integrated gate drivers
Data Sheet
package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

RIC70847F
RIC70847F
Data Sheet

Product details

  • Channels
    2
  • Configuration
    High-side and low-side
  • Output Voltage ((V))
    6.5
  • Package
    C-FP-24, 24-Lead Flatpack
  • Supply Voltage
    4.75 V to 17.1 V
  • TID max
    100 Krad(Si)
  • VS
    17.1 V
Recommended
OPN
Product Status active and preferred
Infineon Package
C-FP-24
Package Name N/A
Packing Size N/A
Packing Type N/A
Moisture Level N/A
Moisture Packing N/A
Lead-free No
Halogen Free Yes
RoHS Compliant No
Infineon stock last updated:

Product Status
Active
Infineon Package
C-FP-24
Package Name -
Packing Size 0
Packing Type
Moisture Level -
Moisture Packing
Lead Free
Halogen Free
RoHS Compliant
RIC70847 is a radiation-hardened synchronous buck controller designed for harsh environments, such as space applications. It features integrated gate drivers and is specified for operation up to 100 krad(Si) total ionizing dose and single event effects (SEE) up to 81.9 MeV·cm²/mg linear energy transfer.

Features

  • Wide supply range
  • Wide load output range
  • Integrated 5 V half bridge gate driver
  • Integrated fault protections
  • MIL-PRF-38535, Class V qualified
  • Single event effect (SEE) hardened
  • Radiation tolerant
