Please note that this is an end of life product. See newer alternative product version Please note that this is an end of life product. See newer alternative product version
END OF LIFE
discontinued
RoHS Compliant
Lead-free

PVI1050N

END OF LIFE
2 Form A Photovoltaic Isolator in a 8-pin DIP Package
Data Sheet

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

PVI1050N
PVI1050N
Data Sheet

Product details

  • Control Current (nominal) min
    10 mA
  • Language
    SPICE
  • Output Voltage
    5 V
  • Product Category
    Photovoltaic Isolators
  • Short Circuit Current min
    5 µA
  • Technology
    MER
  • Type
    2 Form A
OPN
PVI1050NPBF
Product Status discontinued
Infineon Package DIP8
Package Name N/A
Packing Size 2000
Packing Type TUBE
Moisture Level N/A
Moisture Packing NON DRY
Lead-free Yes
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:

Product Status discontinued
Infineon Package DIP8
Package Name -
Packing Size 2000
Packing Type TUBE
Moisture Level -
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
5 V, 5 µA dual channel Photovoltaic MOSFET driver with integrated fast turn-off in a 8-pin DIP package.

Features

  • Isolated voltage source
  • 4.000 Vrms I/O isolation
  • Monolithic construction
  • 1.200 V (DC) output-to-output isol.
  • Solid state reliability
  • Integrated fast turn-off circuitry

Applications
