Active and preferred
RoHS Compliant
Lead-free

OPTIGA TPM SLB 9672 FW15

Ready-to-use TPM with SPI interface and PQC-protected firmware update mechanism optimized for PCs and servers
Data Sheet
package
board
software
Multiple OPNs available
ea.

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

OPTIGA TPM SLB 9672 FW15
OPTIGA TPM SLB 9672 FW15
ea.
Data Sheet

Product details

  • Additional Information
    Version 2.0 Rev. 01.59
  • Ambient Temperature
    -40 °C to 85 °C, -20 °C to 85 °C
  • Applications
    Trusted computing, Servers, PC and mobile computing with Intel x86
  • Asymmetric Cryptography
    RSA1024, RSA2048, RSA3072, RSA4096, ECC NIST P384, ECC BN256, ECC NIST P256
  • Certifications
    CC EAL4+, FIPS 140-2 level 2
  • CPU
    32-bit
  • Delivery Forms
    UQFN-32
  • Interfaces
    SPI
  • NVM
    51 kByte
  • Package
    UQFN-32
  • Product Description
    FW15.xx, TPM for computing platforms (PC and Server)
  • Symmetric Cryptography
    SHA-1, SHA2-256, SHA2-384, HMAC
  • Use Cases
    TPM, PC (Laptop, Desktop) and Server
Recommended
OPN
SLB9672VU20FW1524XTMA1 SLB9672XU20FW1524XTMA1 SLB9672VU20FW1523XTMA1 SLB9672XU20FW1523XTMA1 SLB9672XU20FW1522XTMA1 SLB9672VU20FW1522XTMA1
Product Status active and preferred active and preferred not for new design not for new design discontinued discontinued
Infineon Package
PG-UQFN-32
PG-UQFN-32
PG-UQFN-32
PG-UQFN-32
PG-UQFN-32
PG-UQFN-32
Package Name N/A N/A N/A N/A N/A N/A
Packing Size 5000 5000 5000 5000 5000 5000
Packing Type TAPE & REEL TAPE & REEL TAPE & REEL TAPE & REEL TAPE & REEL TAPE & REEL
Moisture Level 1 1 1 1 1 1
Moisture Packing NON DRY NON DRY NON DRY NON DRY NON DRY NON DRY
Lead-free Yes Yes Yes Yes Yes Yes
Halogen Free Yes Yes Yes Yes Yes Yes
RoHS Compliant Yes Yes Yes Yes Yes Yes
Infineon stock last updated:
 ea. in stock ea. in stock

Product Status
Active
Infineon Package
PG-UQFN-32
Package Name -
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant

Product Status
Active
Infineon Package
PG-UQFN-32
Package Name -
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant

Product Status not for new design
Infineon Package
PG-UQFN-32
Package Name -
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock

Product Status not for new design
Infineon Package
PG-UQFN-32
Package Name -
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock

Product Status discontinued
Infineon Package
PG-UQFN-32
Package Name -
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant

Product Status discontinued
Infineon Package
PG-UQFN-32
Package Name -
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
OPTIGA™ TPM SLB 9672 FW15.xx is the primary choice for Microsoft Windows environments/ecosystems and connected devices with a PC architecture. It provides a solid foundation for securely establishing the identity and software status of PCs and servers. This TPM comes with extended memory and stronger cryptographic algorithms. It is the first TPM in the market that offers a PQC-protected firmware update mechanism using XMSS signatures.

Features

  • Standardized security controller
  • SPI interface
  • Extended non-volatile memory (51 kB)
  • Asym. Crypto up to RSA-4k & ECC P384
  • Symmetric crypto up to AES 256
  • Hash up to SHA2-384
  • Windows HLK certification
  • TCG, CC and FIPS 140-2 certifications
  • Compliant w/ TCG TPM Lib. Spec (v.1.59)
  • Compliant w/ TCG PC Client PTP (v.1.05)
  • PQC-protected FW update mechanism
  • Thin UQFN-32 package

Benefits

  • Proven, turnkey security solution
  • High confidence level (CC/FIPS certs)
  • Faster cryptographic operations
  • Easy integration w/ Windows/Linux OS Pl.

Diagrams

Overview of differences in the OPTIGA™ TPM features and applications
Overview of differences in the OPTIGA™ TPM features and applications
Overview of differences in the OPTIGA™ TPM features and applications Overview of differences in the OPTIGA™ TPM features and applications Overview of differences in the OPTIGA™ TPM features and applications
Embedded Computing Design’s Best in Show Award Winner Embedded Computing Design’s Best in Show Award Winner Embedded Computing Design’s Best in Show Award Winner
Elektronik´s Products of the Year 2023 Award Winner Elektronik´s Products of the Year 2023 Award Winner Elektronik´s Products of the Year 2023 Award Winner
×
