ISO1H815G
Active and preferred
RoHS Compliant

ISO1H815G

Isolated 8-channel HS-switch for industrial automation with parallel uC interface and global diagnosis.
Datasheet
package
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

ISO1H815G
ISO1H815G
ea.
Datasheet


Product details

  • Budgetary Price €/1k
    4.48

Recommended
OPN
ISO1H815GAUMA1
Product Status active and preferred
Infineon Package
PG-DSO-36
Package Name N/A
Packing Size 800
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead-free No
Halogen Free Yes
RoHS Compliant Yes
Country of Assembly (CoA)
ID
Country of Diffusion (CoD)
AT
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-DSO-36
Package Name -
Packing Size 800
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
Country of Assembly (CoA)
ID
Country of Diffusion (CoD)
AT
ea.
in stock
ISOFACE™ ISO1H815G is a 8-channel galvanically isolated high-side switch for the usage in industrial automation environments, such as digital outputs for PLCs, industrial robots, drives & machinery or windpower but as well for driving all kind of actuators and valves. It features a parallel uC interface, 1.2 A output current per channel, integrated protection features and global diagnostic feedback (channel overtemperature and VBB fault).

Features

  • 8-channel high-side switch
  • 1.2 A load current per channel
  • VISO = 500Vrms isolation voltage
  • 3.3 / 5 V parallel MCU interface
  • Overload and short-circuit protection
  • Overtemperature protection
  • Active clamping for inductive loads
  • Overvoltage protection
  • Loss-of-GND protection
  • Common output disable pin
  • Global diagnosis for temp and VBB faults
  • IEC 61131-2 compliant

Benefits

  • Drives higher power loads
  • Allows compact PLC module design
  • Higher system uptime
  • Reduced isolation-design effort
  • No aging effects of isolation
  • High system reliability
  • Robust designs for harsh environments
  • Supply voltage monitoring
  • Fast fault localization
