Active and preferred
RoHS Compliant
Lead-free

IRS2877AS

ISO 26262 (ASIL-B) compliant Time-of-Flight imager with VGA system resolution
package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

IRS2877AS
IRS2877AS

Product details

  • Ambient Temperature
    -40 °C to 105 °C
  • Classification
    ISO 26262 - compliant, AEC-Q100
  • Pixel amount
    640 x 480 (upscaled VGA)
  • Resolution (Pixel)
    307 K
  • Wavelength
    940 nm
Recommended
OPN
IRS2877ASXUMA1
Product Status active and preferred
Infineon Package
PG-LFBGA-65
Package Name N/A
Packing Size 1500
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package
PG-LFBGA-65
Package Name -
Packing Size 1500
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
IRS2877AS has the same functionality and performance like IRS2877A but is additionally developed according to the ISO 26262 (ASIL-B) standard supporting dedicated safety mechanisms. It offers VGA system resolution (640x480 pxl) at a tiny 1/4“ (4 mm) image circle enabling lens sizes known from mobile phones. Furthermore, the camera module BoM is optimized by an integrated eye-safety functionality and an efficient supply concept with standard 1.8V and 3.3V only while offering best performance in strong sunlight conditions thanks to the 5th generation of ToF pixel design including on-chip suppression of background Illumination (SBI) circuitry in every pixel. The imager comes in a 9x9 mm optical BGA package allowing standard soldering processes.
