not for new design
RoHS Compliant
Lead-free

IPW60R045CP

Data Sheet
package
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

IPW60R045CP
IPW60R045CP
ea.
Data Sheet

Product details

  • Budgetary Price €/1k
    7.82
  • ID (@25°C) max
    60 A
  • ID max
    60 A
  • IDpuls max
    230 A
  • Mounting
    THT
  • Operating Temperature min
    -55 °C
  • Package
    TO247
  • Polarity
    N
  • Ptot max
    431 W
  • QG
    150 nC
  • QG (typ @10V)
    150 nC
  • RDS (on) max
    45 mΩ
  • RDS (on) (@10V) max
    45 mΩ
  • RthJA max
    62 K/W
  • RthJC max
    0.29 K/W
  • Rth
    0.3 K/W
  • VDS max
    600 V
  • VGS(th)
    2.5 V to 3.5 V
OPN
IPW60R045CPFKSA1
Product Status not for new design
Infineon Package
PG-TO247-3
Package Name TO247
Packing Size 240
Packing Type TUBE
Moisture Level NA
Moisture Packing NON DRY
Lead-free Yes
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status not for new design
Infineon Package
PG-TO247-3
Package Name TO247
Packing Size 240
Packing Type TUBE
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
CoolMOS™ CP, Infineon's fifth series of CoolMOS™, is designed for hard and soft switching topologies, CCM PFC as well as PWM for ATX, notebook adapter PDP and LCD TV.

Features

  • Lowest figure of merit R on x Q g
  • Ultra low gate charge
  • Extreme dv/dt rate
  • Ultra low R DS(on), ultra low gate charge, very fast switching
  • V th 3 V, g fs very high, internal R g very low
  • High current capability
  • Significant reduction of conduction and switching losses
  • High power density and efficiency for superior power conversion systems
  • Best-in-class price/performance ratio
