IDW100E60

600 V silicon power diode in TO-247 package
Data Sheet
package
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

IDW100E60
IDW100E60
ea.
Data Sheet

Product details

  • Configuration
    Single
  • I(FSM) max
    400 A
  • IF
    100 A
  • IR max
    40 µA
  • Irrm
    49.5 A
  • Mounting
    THT
  • Operating Temperature
    -55 °C to 175 °C
  • Package
    TO-247
  • Ptot max
    375 W
  • Qrr
    3.6 nC
  • RthJC max
    0.4 K/W
  • trr
    120 ns
  • VF
    1.65 V
  • Voltage Class max
    600 V
Recommended
OPN
IDW100E60FKSA1
Product Status active
Infineon Package
PG-TO247-3
Package Name TO247
Packing Size 240
Packing Type TUBE
Moisture Level NA
Moisture Packing NON DRY
Lead-free Yes
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-TO247-3
Package Name TO247
Packing Size 240
Packing Type TUBE
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
The 600 V, 100 A emitter controlled silicon power diode in a TO-247 package has been primarily designed for motor drive applications up to 30kHz.

Features

  • Lowest VF values
  • Softest diodes avail. on the market
  • Tj(max) of 175°C
  • Qualified according to JEDEC
  • Cooler packages & higher efficiency
  • Excellent EMI behavior
  • Excellent cost/perform. trade-off
  • Low conduction losses
  • Easy paralleling
