IDP30E65D2

650 V silicon power diode in TO-220 real2pin package
Data Sheet
package
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

IDP30E65D2
IDP30E65D2
ea.
Data Sheet

Product details

  • Configuration
    Single
  • I(FSM) max
    180 A
  • IF
    30 A
  • IR max
    40 µA
  • Irrm
    5.7 A
  • Mounting
    THT
  • Operating Temperature
    -40 °C to 175 °C
  • Package
    TO-220
  • Ptot max
    143 W
  • Qrr
    0.25 µC
  • RthJC max
    1.05 K/W
  • trr
    70 ns
  • VF
    1.6 V
  • Voltage Class max
    650 V
Recommended
OPN
IDP30E65D2XKSA1
Product Status active
Infineon Package
PG-TO220-2
Package Name TO220
Packing Size 500
Packing Type TUBE
Moisture Level NA
Moisture Packing NON DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-TO220-2
Package Name TO220
Packing Size 500
Packing Type TUBE
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
Rapid 2 switching 650 V, 30 A emitter controlled power silicon diode in a TO-220 real2pin package is designed for applications switching between 40 kHz and 100 kHz.

Features

  • Lowest reverse recovery charge Qrr
  • VF ratio for BiC performance
  • Low reverse recovery time (trr)
  • Lowest Irrmfor:
  • Lowest losses on boost switch
