FS3L100R07W3S5_B11

650 V, 100 A sixpack IGBT module
Data Sheet

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

FS3L100R07W3S5_B11
FS3L100R07W3S5_B11
Data Sheet

Product details

  • Configuration
    3-level
  • Dimensions (length)
    109.9 mm
  • Dimensions (width)
    62 mm
  • Features
    PressFIT, 3 phases
  • Housing
    EasyPACK™ 3B
  • IC(nom) / IF(nom)
    100 A
  • IC max
    100 A
  • Qualification
    Industrial
  • Technology
    IGBT5 - S5
  • VCE(sat) (Tvj=25°C typ)
    1.17 V
  • VF (Tvj=25°C typ)
    1.3 V
  • Voltage Class max
    650 V
Recommended
OPN
FS3L100R07W3S5B11BPSA1
Product Status active and preferred
Infineon Package AG-EASY3B
Package Name N/A
Packing Size 8
Packing Type TRAY
Moisture Level NA
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package AG-EASY3B
Package Name -
Packing Size 8
Packing Type TRAY
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
EasyPACK™ 3B 650 V, 100 A sixpack IGBT module with TRENCHSTOP™ 5 , NTC and PressFIT contact technology for 1000V DC PV systems in three level NPC1 topology for up to 40 kVA.

Features

  • 1000 V DC system (PV Inverter)
  • Efficiency max. 99% (PV Inverter)
  • Reactive power capability
  • *with cosφ= 0.8 (PV Inverter)
  • Output power ~ 40 kVA (PV Inverter)

Applications

Photovoltaic
