FF1700XTR17IE5D

1700 V, 1700 A dual IGBT module
Data Sheet
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

FF1700XTR17IE5D
FF1700XTR17IE5D
ea.
Data Sheet

Product details

  • Configuration
    half-bridge
  • Dimensions (width)
    89 mm
  • Dimensions (length)
    250 mm
  • Features
    .XT Technology
  • Housing
    PrimePACK™ 3+
  • IC(nom) / IF(nom)
    1700 A
  • IC max
    1700 A
  • Qualification
    Industrial
  • Technology
    IGBT5 - E5
  • VCE(sat) (Tvj=25°C typ)
    1.95 V
  • VCES / VRRM
    1700 V
  • VF (Tvj=25°C typ)
    1.65 V
  • Voltage Class max
    1700 V
Recommended
OPN
FF1700XTR17IE5DBPSA1
Product Status active and preferred
Infineon Package AG-PRIME3+
Package Name N/A
Packing Size 2
Packing Type TRAY
Moisture Level NA
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package AG-PRIME3+
Package Name -
Packing Size 2
Packing Type TRAY
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
3+ 1700 V, 1700 A dual with .XT interconnection technology, TRENCHSTOP™ IGBT5, Emitter Controlled 5 diode and NTC. Optimized for MSC of wind turbine converters.

Features

  • High temperature (Tvjop=175°C) operation
  • 20% higher o/p current than FF1800R17IP5
  • Copper bonds for high current
  • Sintered chips for high power cycling
  • Total losses reduced by up to 20%
  • Package with CTI > 400

Benefits

  • Increase in power density
  • Up to 10 times longer lifetime
  • Less cooling effort
  • Enable higher system overload conditions
