DD380N16A

50 mm Rectifier Diode Module with 1600 V in pressure contact technology
Data Sheet
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

DD380N16A
DD380N16A
ea.
Data Sheet

Product details

  • Configuration
    Rectifier Diode
  • Housing
    50 mm
  • IFAVM/TC / ITAVM/TC [A/°C] (@180° el sin)
    393/100
  • IFSM / ITSM [A] (@10ms, Tvj max)
    12000
  • Product Line
    Power Block
  • rT [mΩ] (@Tvj max)
    0.4
  • RthJC [K/W] (@180° el sin)
    0.112
  • Tvj [°C]
    150
  • VDRM / VRRM [V]
    1600
  • VT0 [V] (@Tvj max)
    0.75
  • ∫I2dt [A²s · 103] (@10ms, Tvj max)
    720
Recommended
OPN
DD380N16AHPSA1
Product Status active and preferred
Infineon Package BG-PB50-1
Package Name N/A
Packing Size 3
Packing Type TRAY
Moisture Level NA
Moisture Packing NON DRY
Lead-free Yes
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package BG-PB50-1
Package Name -
Packing Size 3
Packing Type TRAY
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
Rectifier Diode 50 mm Power Block 1600 V, 380 A module for phase control in pressure contact technology using an isolated copper base plate.

Features

  • Pressure contact for high reliability
  • Advanced medium power technology
  • Best-in-class power density
  • Highest surge current in 50 mm housing
  • Predictable performance over lifetime

Benefits

  • Designed for high overload requirements
  • High DC blocking stability over lifetime
  • High surge current capability
  • One supplier for a broad range of Modules
