Active and preferred
RoHS Compliant
Lead-free

CYPD3123-40LQXI

Data Sheet
package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CYPD3123-40LQXI
CYPD3123-40LQXI
Data Sheet

Product details

  • Applications
    Dongles
  • Family
    EZ-PD™ CCG3
  • Flash
    128 kByte
  • GPIOs
    20
  • Operating Temperature
    -40 °C to 85 °C
  • Operating Voltage
    2.7 V to 21.5 V
  • Package Type
    40-pin QFN
  • Peak Reflow Temp
    260 °C
  • Product Category
    AC-DC DC-DC PD solutions
  • Product Description
    USB Type-C Port Controller
  • Protection features (OVP, OCP, SCP and ESD)
    Y
  • Software Tools
    EZ-PD™ CCG3 SDK
  • SRAM
    8 kByte
  • Temperature grade
    Industrial
  • USB Standard
    USB-PD 3.0
  • VBUS Short Protection
    Y
  • VCONN FET
    Y
Recommended
OPN
CYPD3123-40LQXI
Product Status active and preferred
Infineon Package
PG-VQFN-40
Package Name QFN-40 (001-80659)
Packing Size 4900
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package
PG-VQFN-40
Package Name QFN-40 (001-80659)
Packing Size 4900
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
