CY29430FLQXI
Active
RoHS Compliant
Lead-free

CY29430FLQXI

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CY29430FLQXI
CY29430FLQXI

Product details

  • Category
    High Performance Programmable XO
  • Core/IO Operating Voltages ((V))
    1.8/2.5/3.3
  • Features
    Programmable High-Frequency Crystal Oscillator
  • I/O Voltage ((V))
    1.8/2.5/3.3
  • Input Frequency range
    40 MHz to 133 MHz
  • Input Type
    Xtal/Ref-in CMOS
  • Lead Ball Finish
    Pure Sn
  • On-chip Clock Generation (PLL)
    1
  • Operating Temperature range
    -40 °C to 105 °C
  • Operating Voltage range
    1.71 V to 3.63 V
  • Output Frequency range
    15 MHz to 2100 MHz
  • Output Signal Type
    Differential
  • Outputs
    1
  • Peak Reflow Temp
    260 °C
  • Publish in NPSG
    Y
  • Publish in PSG
    Y
  • Qualification
    Industrial
  • Spread Spectrum
    N
OPN
CY29430FLQXI
Product Status active
Infineon Package
Package Name QFN-16 (001-87187)
Packing Size 980
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package
Package Name QFN-16 (001-87187)
Packing Size 980
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
The CY29430FLQXI is a high-performance programmable crystal oscillator with low-noise PLL and integrated VCO. It supports 40.0 to 133.0 MHz input and 15.0 to 2100.0 MHz differential output, operates from 1.71 to 3.63 V, and is I2C configurable. Qualified for industrial use, it operates from -40 to 105°C in a 16-pin QFN package. Ideal for communications, networking, and instrumentation.

Features

  • Programmable PLL with fractional-N
  • Four independent differential outputs
  • Output frequency range: 15 MHz to 2.1
  • Supports LVPECL, LVDS, CML, HCSL, LVCMOS
  • Integrated VCXO, tunable TPR ±50 to ±275
  • I2C interface, programmable settings
  • Typical jitter: 110-190 fs
  • No special power supply sequencing
  • Small/large frequency change via I2C/FS
  • Programmable OE polarity
  • Non-volatile memory for configuration
  • Crystal or clock input (HFF, OT3, LFF)

Benefits

  • Flexible clocking for diverse
  • Multiple outputs simplify system design
  • Wide frequency range fits many systems
  • Compatible with major output standards
  • VCXO enables precise clock adjustment
  • Easy configuration via I2C
  • Low jitter ensures signal integrity
  • Simple power-up, no sequencing hassle
  • On-the-fly frequency changes
  • Customizable output enable logic
  • Retains settings after power cycle
  • Supports various reference sources
