AS5311

AS5311

12-bit linear incremental position sensor with digital interface and ABI, PWM output
Datasheet

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

AS5311
AS5311
Datasheet


Product details

  • Die in package
    single
  • Function
    off-axis angle position sensing, linear position sensing
  • Operating ambient temperature range
    -40 °C to 125 °C
  • Output interface
    PWM, ABI, SSI
  • Resolution
    12 bit
  • Supply Voltage
    3.3 V, 5 V
  • Technology
    magnetic

OPN
Product Status
Infineon Package
Package Name
Packing Size
Packing Type
Moisture Level
Moisture Packing
Lead-free
Halogen Free
RoHS Compliant
The AS5311 is an incremental position sensor for linear and rotary off-axis applications based on contactless magnetic sensor technology. To measure position and motion a multi-pole magnet strip or ring has to be used. There are 4096 pulses (12-bit) per 2.0 mm pole pair length on the standardized quadrature output interface with an index pulse (=ABI-interface) with a maximum speed of 650mm/s.

Features

  • Contactless motion and position sensing
  • High resolution
  • Immune to external magnetic stray fields

Benefits

  • High reliability and durability in harsh environments
  • Control of high precision movements
  • Lower material cost (no magnetic shielding needed)

Applications
