AS5173

AS5173

Low-noise and, High-resolution on-axis magnetic angular position sensor with PSI5 output
Datasheet

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

AS5173
AS5173
Datasheet

Product details

  • Accurancy
    0.4 °
  • ASIL qualified
    ASIL B
  • Automotive Qualified
    AEC-Q100
  • Die in package
    single
  • Function
    on-axis angle position sensing
  • Operating ambient temperature range
    -40 °C to 125 °C
  • Output interface
    PSI5
  • Resolution
    14 bit, 12 bit
  • Supply Voltage
    7 V
  • Technology
    magnetic
OPN
Product Status
Infineon Package
Package Name
Packing Size
Packing Type
Moisture Level
Moisture Packing
Lead-free
Halogen Free
RoHS Compliant
Infineon stock last updated:
High‑precision magnetic position sensor with configurable 12‑bit or 14‑bit PSI5 output (PSI5 v1.3/2.3) for accurate full 360° angle measurement. Hall‑based analog front-end ensures reliable operation and strong stray‑field immunity. Supports programmable sub‑range for optimized resolution. Requires simple 2‑pole magnet. Robust automotive design with up to 16.5 V operation, +20 V overvoltage and −18 V reverse polarity protection.

Features

  • 12-bit resolution @90° minimum arc
  • Low output noise, low inherent INL
  • Magnetic stray field immunity
  • Functional safety, diagnostics
  • AEC-Q100 Grade 1 qualified
  • System cost reduction: PCB less + reduced BOM

Benefits

  • Resolve small angular excursion with high accuracy
  • Accurate angle measurement
  • Higher durability and lower system costs (no shield needed)
  • Enabler for safety critical applications
  • Suitable for automotive applications
  • SIP Package (System-in-Package)
