TLF4477-3LA BOARD

NEW
The TLF4477-3LA demoboard allows evaluation of the TLF4477-3LA in the PG-TSON-14 package.
User Manual

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

TLF4477-3LA BOARD
TLF4477-3LA BOARD
User Manual

Product details

  • Board Type
    Evaluation Board
  • Family
    Linear Voltage Regulator (LDO), OPTIREG™ Linear
  • Input Type
    DC
  • Language
    SPICE
  • Operating Voltage max
    40 V
  • Output Voltage
    3 V to 20 V
  • Product Category
    Evaluation Boards
  • Qualification
    Automotive
  • Sub Application
    Antenna supply
  • Target Application
    Automotive
  • Topology
    Linear
Recommended
OPN
TLF44773LABOARDTOBO1
Product Status active and preferred
Infineon Package N/A
Package Name N/A
Packing Size 1
Packing Type CONTAINER
Moisture Level NA
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant No
Infineon stock last updated:

Product Status
Active
Infineon Package N/A
Package Name -
Packing Size 1
Packing Type CONTAINER
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
The TLF4477-3LA demoboard allows evaluation of the TLF4477-3LA in the PG-TSON-14 package. The TLF4477-3LA demoboard evaluates Infineon’s latest high performance dual channel automotive LDO with integrated current sense. The TLF4477-3LA has been designed for all ECUs connected to the battery within the infotainment automotive application that need a current sense for active antenna diagnostics. It allows for an easy plug-and-play solution to evaluate the TLF4477-3LA with all necessary external components already mounted on the board.

Features

  • Plug-and-play evaluation capability
  • Easy verification and configuration
  • Enable, current sense
  • Overtemperature shutdown
  • Output current limitation
  • Adjustable output voltage
  • AEC-Q100 qualified

Benefits

  • Save design time
  • Allow easy adaption for evaluation

Applications
