TLE997X EVALKIT

NEW
The MOTIX™ TLE997x Evaluation Kit offers evaluation of all functions and peripherals of TLE9976QXW40

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

TLE997X EVALKIT
TLE997X EVALKIT

Product details

  • Dimensions
    105mm x 89mm
  • Family
    MOTIX™ 32-bit motor control SoC
  • Input Type
    DC
  • Product Category
    Evaluation Board
  • Qualification
    Automotive
  • Sub Application
    Water pump, electric coolant pump, oil pump, cooling fan, actuator control valve, power sliding door
  • Supply Voltage range
    5.5 V to 29 V
  • Topology
    B6 Bridge, 3-Phase Motor, 2-Phase Motor
OPN
Product Status
Infineon Package
Package Name
Packing Size
Packing Type
Moisture Level
Moisture Packing
Lead-free
Halogen Free
RoHS Compliant
Infineon stock last updated:
The MOTIX™ TLE997x Evaluation Kit is designed to provide a complete evaluation of the TLE9976QXW40, the super set device that offers the entire range of functionalities available in the MOTIX™ TLE997x series. This enables developers to fully explore and assess all functions and peripherals of the device, making it an ideal platform for development and testing.

Features

  • 3-phase MOSFET bridge
  • Sensorless/sensor-based motor control
  • Interface for analog sensors (ADC)
  • Interface for digital sensors (SPI)
  • Onboard debugging interface
  • Compatible with example software
  • Pin header for all signals
