REF-ICL5102-U52W-CC

52W LED driver PFC+LCC evaluation board with ICL5102
Application Notes
board
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

REF-ICL5102-U52W-CC
REF-ICL5102-U52W-CC
ea.
Application Notes

Product details

  • Board Type
    Evaluation Board
  • Dimensions
    100mm×63mm×25mm
  • Family
    LED Driver
  • Frequency
    170 kHz to 220 kHz
  • Input Type
    AC
  • Output Current
    0.78 A to 1 A
  • Output Voltage
    20 V to 52 V
  • Pout
    52 W
  • Product Name
    REF-ICL5102-U52W-CC
  • Qualification
    Industrial
  • Supply Voltage
    198 V to 256 V
  • Target Application
    LED Lighting, Lighting
  • Topology
    LLC
Recommended
OPN
REFICL5102U52WCCTOBO1
Product Status active and preferred
Infineon Package --
Package Name N/A
Packing Size N/A
Packing Type N/A
Moisture Level N/A
Moisture Packing N/A
Lead-free No
Halogen Free No
RoHS Compliant No
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package --
Package Name -
Packing Size 0
Packing Type
Moisture Level -
Moisture Packing
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
The REF-ICL5102-U52W-CC demonstrates a low-cost PFC+LCC LED driver for non-dimmable indoor lighting applications, offering three fixed LED current levels. The LCC utilizes open loop control and a compact integrated transformer, resulting in a low system cost. The high-frequency operation enables integration of the series inductance into the transformer, contributing to cost-effectiveness.

Features

  • Low cost PFC+LCC topology for non-dimmable LED lighting where high light quality is required
  • Open-loop LCC design with narrow LED current spread
  • Integrated LCC transformer
  • Feedforward to constrain the LED current spread in the open-loop design
  • High frequency LCC

Benefits

  • Low cost, high efficiency
  • Superior THD
  • Compact LCC magnetics
  • Narrow LED current spread in the open loop design
  • High frequency LCC

Applications

Bill of Material

Documents

Documents

Design resources

Partner solutions

Developer community
