REF_AUDIO_SIC_2KW
Active and preferred
RoHS Compliant

REF_AUDIO_SIC_2KW

2-channel 1000 W/ch half-bridge class D audio power amplifier featuring 400 V CoolSiCTM and IRS2452BM controller IC.
User manual

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

REF_AUDIO_SIC_2KW
REF_AUDIO_SIC_2KW
User manual


Product details


Recommended
OPN
REFAUDIOSIC2KWTOBO1
Product Status active and preferred
Infineon Package --
Package Name N/A
Packing Size 1
Packing Type CONTAINER
Moisture Level N/A
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package --
Package Name -
Packing Size 1
Packing Type CONTAINER
Moisture Level -
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
The REF_AUDIO_SIC_2KW is a high-efficiency class D audio evaluation board that demonstrates the advantages of 400 V CoolSiCTM G2 transistors in professional audio applications. This reference design enables both constant voltage (High-Z) and low impedance (Low-Z) operation, making it suitable for a wide range of commercial and high performance sound reinforcement systems.

Features

  • Over current protection, high-side and low-side
  • Over-voltage protection
  • Under voltage protection
  • Over-temperature protection
  • Self-oscillating half-bridge topology
  • Onboard clock synchronization

Benefits

  • High and Low Impedance compatible
  • High efficiency
  • Scalable up to 1000 W per channel
  • Increased power output up to 3000W x 2ch with larger heatsink is achievable
  • Low noise
