BGS110MN20 BOARD
BGS110MN20 BOARD

Product details

OPN
BGS110MN20BOARDTOBO1
Product Status on request
Infineon Package --
Package Name N/A
Packing Size 1
Packing Type CONTAINER
Moisture Level N/A
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant No
Infineon stock last updated:

Product Status on request
Infineon Package --
Package Name -
Packing Size 1
Packing Type CONTAINER
Moisture Level -
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
The BGS110MN20 is a Single Pole Ten Throw (SP10T) Diversity Switch Module for multi-mode WCDMA/LTE applications up to 2.7 GHz. It features ultra-low insertion loss, high port-to-port isolation, 10 high-linearity, interchangeable RX ports, and supports a wide voltage range from 2.5V to 5.5V. It includes an integrated MIPI RFFE interface and does not require decoupling capacitors if no DC is applied on RF lines.

Features

  •  Suitable for multi-mode WCDMA / LTE diversity applications
  • Ultra-low insertion loss and harmonics generation
  • 10 high-linearity, interchangeable RX ports
  • 0.1 to 2.7 GHz coverage
  • High port-to-port-isolation
  • Direct to battery supply enabled by large supply voltage range from 2.5 V to 5.5 V
  • Integrated MIPI RFFE interface supporting 1.2 and 1.8 V bus voltage
  • Software programmable MIPI RFFE USID
  • No decoupling capacitors required if no DC applied on RF lines
