TLF12505A

OPTIREG™ multiphase: Integrated Power Stage optimized for Automotive Applications
Data Sheet
package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

TLF12505A
TLF12505A
Data Sheet

Product details

Recommended
OPN
TLF12505AAUMA1
Product Status active and preferred
Infineon Package
PG-VIQFN-36
Package Name N/A
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead-free No
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package
PG-VIQFN-36
Package Name -
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
The AEC-Q100 qualified TLF12505A integrated power stage is member of the OPTIREG™ multiphase product family and is optimized to fit to requirements derived from the automotive segment by utilizing a new unique package for improved thermal-cycle and long-term reliability and robustness. The input voltage range is extended to 20 V, enabling connection to 12 V power net of an EV without pre-regulator.

Features

  • 60 A thermal design current (TDC)
  • Wide input voltage range up to 20 V
  • Operation up to 2 Mhz
  • Integrated current sensing
  • Advanced protection features
  • Advanced fault reporting
  • Optimized package for automotive use
  • Automotive AEC-Q100 Rev H Grade 1

Benefits

  • Simple and easy to use
  • High efficiency by EV board net link
  • Minimum external components needed
  • High frequency reduced BOM size and cost
  • Increased system reliability
  • Simplified fault root cause analysis
  • Better thermal-cycle reliability
  • Improved robustness

Applications
