SLM 97CFX1M00PE

High-end performance for eSIM applications, simplifying the deployment of new M2M solutions

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

SLM 97CFX1M00PE
SLM 97CFX1M00PE

Product details

  • Ambient Temperature
    -40 °C to 105 °C
  • Applications
    industrial applications, eSIM
  • Asymmetric Cryptography
    ECC up to 521-bit, RSA up to 4096-bit
  • Certifications
    CC EAL5+ high
  • CPU
    32-bit
  • Delivery Forms
    P-M2M4.7, WF WLB-16, sawn wafer, MFF2
  • Interfaces
    ISO 7816
  • Leading Technologies
    SOLID FLASH™
  • NVM / 凌捷掩膜
    1 MByte
  • Package
    MFF2, P-M2M4.7
  • Product Description
    security cryptocontroller, optimized for industrial applications (eSIM)
  • RAM
    32 kByte
  • Symmetric Cryptography
    DES, 3DES, AES up to 256-bit
OPN
Product Status
Infineon Package
Package Name
Packing Size
Packing Type
Moisture Level
Moisture Packing
Lead-free
Halogen Free
RoHS Compliant
Infineon stock last updated:
Available in different memory sizes, the SLM 97 family is a fit for purpose security controller. Thanks to its CC EAL5+ certification and its crypto-coprocessor options, it is the perfect companion for M2M SIM and GSMA SGP.02/32 eSIM applications running in difficult environmental and usage conditions. The SLM 97CFX1M00PE has 1016 kB of NVM.

Features

  • 32-bit CPU
  • 1016 kB SOLID FLASH™
  • Asymmetric (ECC/RSA) cryptography
  • Symmetric (AES/DES) cryptography
  • ISO 7816 interface
  • Industrial grade ( -40° to 105°C)
  • CC EAL 5+ high
  • 32 kB RAM

Applications
