SLE 78CLFX500VPH
SLE 78CLFX500VPH

Product details

  • Ambient Temperature
    -25 °C to 85 °C
  • Applications
    government identification
  • Asymmetric Cryptography
    ECC up to 521-bit, RSA up to 4096-bit
  • Certifications
    EMVCo, CC EAL6+ high
  • CPU
    Dual 16-bit
  • Delivery Forms
    dual-interface module, contactless module, sawn wafer
  • Interfaces
    ISO 7816, ISO 18092 passive mode, ISO 14443 A/B, NRG™ (ISO/IEC 14443-3 type A with CRYPTO1)
  • Leading Technologies
    Very High Bit Rates (VHBR), SOLID FLASH™, Mega Memory, Integrity Guard
  • NVM / 凌捷掩膜
    528 kByte
  • Product Description
    contactless security cryptocontroller with dual-interface
  • RAM
    12 kByte
  • Symmetric Cryptography
    AES up to 256-bit, DES, 3DES
  • Use Cases
    National eID, ePassport, eHealth card / eSocial card, eDriver’s license, eVisa, eResidence permit, eTachograph, eVehicle registration card / eCar registration, eSignature
OPN
Product Status
Infineon Package
Package Name
Packing Size
Packing Type
Moisture Level
Moisture Packing
Lead-free
Halogen Free
RoHS Compliant
Infineon stock last updated:
SLE 78 SOLID FLASH™ dual-interface and contactless security cryptocontrollerCertification to Common Criteria EAL 6+ (high)Cache-based pure 16-bit security controller designed for all requirements for secure eGovernment. It is well-suited for long document life times. The SOLID FLASH™ based controller cuts the time-to market and the time-to project to unprecedented levels.

Features

  • Outstanding digital security concept Integrity Guard
  • SOLID FLASH™ memory
  • Self-checking dual CPU
  • Fully encrypted data path including encrypted calculation in the CPU.
  • Certification to Common Criteria  EAL 6+ (high)
  • Support for all contactless proximity standards (ISO 14443 type A&B, ISO 18092 NFC passive mode)
