SAF-XC822MT-1FRI AA
SAF-XC822MT-1FRI AA


Product details

  • A/D Input Lines (incl. FADC)
    4
  • Additional Features
    Industrial
  • Budgetary Price €/1k
    1.22
  • CAN Nodes
    0
  • Digital I/O Pins
    0
  • DMA Channels
    0
  • DSP Functionality
    Yes
  • EEPROM Emulation
    Yes
  • External Bus Interface
    No
  • Fast Flash Programming
    No
  • Floating Point Unit
    No
  • I/O Operation Voltages
    5 V, 3.3 V
  • Instruction Width ([bits])
    8
  • Number of ADC Modules
    1
  • On-chip Clock Generation
    Yes
  • On-chip Voltage Regulator
    Yes
  • Oscillator Watchdog
    Yes
  • Power Mode
    4
  • Program Memory
    4 kByte
  • Qualification
    Industrial
  • Real Time Clock
    Yes
  • Serial I/O Interfaces
    3
  • SRAM (incl. Cache)
    0.5 kByte
  • Temperature
    -40 to 85°C
  • Timed I/O Pins (PWM, CAPCOM)
    4
  • Timer/Counter
    0
  • Touch/LED Matrix Control
    Yes
  • Type of Memory
    Flash
  • Type of Serial I/O Interfaces
    I²C, SPI, UART
  • Watchdog Timer
    Yes

OPN
Product Status
Infineon Package
Package Name
Packing Size
Packing Type
Moisture Level
Moisture Packing
Lead-free
Halogen Free
RoHS Compliant
Communication interfaces and fast control loops with multichannel 10-bit ADCs and PWM signal generation are featured as well as safety and low power modes. The MDU co-processor boosts up standard 8-bit processing performance.

Features

  • Package: PG-TSSOP-16
  • CAN Nodes: 0
  • Program Memory: 4.0 KByte
  • FlexRay™: no
  • Type of Serial I/O Interfaces: 1xUART, 1SSC, I2C
