Active and preferred
RoHS Compliant
Lead-free

CYUSB2315-BF104AXI

EZ-USB™ FX2G3 is a family of highly-integrated USB 2.0 controllers serving as the basis for any 480 Mbps USB peripheral device. CYUSB2315 is the most basic variant of this family and it comes with ARM® Cortex® M0+ CPU, I2C and UART support.
Data Sheet
package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CYUSB2315-BF104AXI
CYUSB2315-BF104AXI
Data Sheet

Product details

  • Applications
    Camera, Medical Imaging, Scanners
  • Family
    EZ-USB™ FX2G3
  • Operating Temperature
    -40 °C to 85 °C
  • Operating Voltage
    1.7 V to 3.6 V
  • Package Type
    104-LGA
  • Product Description
    USB HighSpeed peripheral controller
  • Software Tools
    EZ-USB™ FX SDK, GPIF III Designer
  • Temperature grade
    Industrial
  • USB Speed
    480 MBit/s
  • USB Standard
    USB 2.0 HS
Recommended
OPN
Product Status active and preferred
Infineon Package
PG-VFLGA-104
Package Name N/A
Packing Size 1740
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package
PG-VFLGA-104
Package Name -
Packing Size 1740
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
USB 2.0 480 Mbps controller with I2C and UART support (tray)

Features

  • USB 2.0 high speed: 480 Mbps
  • 16-bit GPIF/FIFO
  • ARM® Cortex®-M0+ CPU
  • 512 + 128 KB SRAM, 256 KB Flash
  • Integrated USB-C Mux
  • UART & I2C support
  • Compact 8 x 8 mm 104-QFN package
  • Dedicated SW development platform
  • Tray packing

Benefits

  • Achieve faster, scalable data transfers
  • Enhanced processing power and memory
  • Broad compatibility with comm. support
  • Compact package for space-contraints
  • Streamlined development ecosystem
