Active and preferred
RoHS Compliant
Lead-free

CYPD4236-40LQXQ

package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CYPD4236-40LQXQ
CYPD4236-40LQXQ

Product details

  • # of ports
    Dual
  • Applications
    Dual Port Power Adapter
  • Family
    EZ-PD™ CCG4
  • Flash
    128 kByte
  • GPIOs
    30
  • Operating Temperature
    -40 °C to 105 °C
  • Operating Voltage
    2.7 V to 5.5 V
  • Package Type
    40-Pin QFN
  • Peak Reflow Temp
    260 °C
  • Processor Type
    ARM® Cortex®-M0
  • Product Category
    PD controllers
  • Product Description
    Dual port Type-C controller
  • Protection features (OVP, OCP, SCP and ESD)
    N
  • Software Tools
    PSoC™ Creator
  • SRAM
    8 kByte
  • Temperature grade
    Extended Industrial
  • USB Standard
    USB-PD 3.0
  • VBUS Short Protection
    Y
  • VCONN FET
    N
Recommended
OPN
CYPD4236-40LQXQ
Product Status active and preferred
Infineon Package
PG-VQFN-40
Package Name QFN-40 (001-80659)
Packing Size 4900
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package
PG-VQFN-40
Package Name QFN-40 (001-80659)
Packing Size 4900
Packing Type TRAY
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
