TLS715B0EJ V50 BOARD
TLS715B0EJ V50 BOARD
User Manual

Product details

  • Board Type
    Evaluation Board
  • Family
    OPTIREG™ Linear, Linear Voltage Regulator (LDO)
  • Input Type
    DC
  • Output Voltage
    5 V
  • Qualification
    Automotive
  • Sub Application
    Dashboard, Gateway, Infotainment, Start-Stop Control Unit, Clima Control (HVAC), Body Module, Automotive General ECU, Alarm
  • Supply Voltage
    13.5 V
  • Target Application
    Automotive
  • Topology
    Linear
Recommended
OPN
TLS715B0EJV50BOARDTOBO1
Product Status active and preferred
Infineon Package N/A
Package Name N/A
Packing Size 1
Packing Type CONTAINER
Moisture Level NA
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant No
Infineon stock last updated:

Product Status
Active
Infineon Package N/A
Package Name -
Packing Size 1
Packing Type CONTAINER
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
TLS715B0 is a low dropout linear voltage regulator (up to 150mA). Regulates input voltage (up to 40V) to VQ,nom = 5V (±2% precision). Ideal for low current systems (36μA), battery-connected. Dropout voltage: 200mV (< 100mA). Extended operating range from 4.0V, suitable for automotive start-stop. Features current limitation, over-temperature shutdown, protection against failures. For stabilizing 5V supply voltage in various applications.

Features

  • input voltage range from 4.0 V to 40 V
  • Output voltage 5 V
  • Output voltage precision ± 2%
  • Output current up to 100 mA
  • Low current consumption of 40 μA
  • Very low dropout Voltage of typ. 200 mV
  • temperature range from -40°C up to 150°C
  • Green Product (RoHS compliant)
  • AEC Qualified
