TLS4120 ADJBOARD L
TLS4120 ADJBOARD L
User Manual

Product details

  • Board Type
    Demo Board
  • Family
    OPTIREG™ Switcher
  • Input Type
    DC
  • Output Voltage
    3 V to 10 V
  • Qualification
    Automotive
  • Sub Application
    Camera, Radar, Gateway, BCM, ADAS, Power supply for any automotive ECU, Infotainment, Car-Media, Telematics
  • Supply Voltage
    13.5 V
  • Topology
    DC-DC converter
OPN
TLS4120ADJBOARDLTOBO1
Product Status on request
Infineon Package --
Package Name N/A
Packing Size 1
Packing Type CONTAINER
Moisture Level N/A
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant No
Infineon stock last updated:

Product Status on request
Infineon Package --
Package Name -
Packing Size 1
Packing Type CONTAINER
Moisture Level -
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
The TLS4120D0EPV is a synchronous step-down DC/DC converter for automotive applications. It has a current capability of 2A and an adjustable output voltage of 3V-10V. Integrated power stages, soft start feature, and compensation minimize external components and system costs. With a wide input voltage range and 100% duty-cycle operation, it is suitable for battery cranking scenarios. TLS4120 ADJBOARD L supports its low switching frequency range.

Features

  • Wide input voltage range covers majority of automotive applications
  • Adjustable (3V-10V) output voltage
  • Max continues output current of 2A
  • Optimized for size and flexibility
  • Low quiescent current operation at no load condition
