BTS7200-4EPA DAUGH BRD

SMART7 PROFET+2 12V BTS7200-4EPA DAUGHTER BOARD
User Manual

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

BTS7200-4EPA DAUGH BRD
BTS7200-4EPA DAUGH BRD
User Manual

Product details

  • Board Type
    Evaluation Board
  • Family
    High-side switches, PROFET™ +2 12V
  • Input Type
    DC
  • Qualification
    Automotive
  • Sub Application
    Body Control, Lighting
  • Supply Voltage min
    -16 V
  • Supply Voltage max
    35 V
  • Target Application
    Automotive
  • Topology
    High-side switch
Recommended
OPN
BTS72004EPADAUGHBRDTOBO1
Product Status active and preferred
Infineon Package N/A
Package Name N/A
Packing Size 1
Packing Type CONTAINER
Moisture Level NA
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant No
Infineon stock last updated:

Product Status
Active
Infineon Package N/A
Package Name -
Packing Size 1
Packing Type CONTAINER
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
This daughterboard comes with 1 high-side switch of BTS7200-4EPA and is compatible with the PROFET™+2 12V motherboard. The purpose of this board is to provide a quick pick and place solution for costumers' lab evaluations. The motherboard in combination with the daugtherboard is capable to drive typcial automotive loads.

Features

  • Operating V R 3.1-28V with 3.3.V and 5V
  • Protection: current tripping,overvoltage
  • Diagnosis: load current sense output
  • Optimized flexibility across the family
  • Miniaturization / Shrink of the PCB Area

Benefits

  • 50% reduced current consumption
  • Current sense accuracy (kILIS) ≤ 5%
  • Smaller package size for area savings
  • Very low output leakage current

Applications

Bill of Material

Documents

Documents

Design resources

Partner solutions

Developer community
